Palomar Q5 Laser

The Q5 Cosmetic General Q-Switched Nd:YAG Laser is a professional aesthetic treatment system designed for effective tattoo removal and treatment of pigmented skin lesions. Utilizing advanced Q-switched laser technology, this system delivers high-energy pulses in nanoseconds to safely break down ink pigments and excess melanin without damaging surrounding tissue.

Equipped with dual wavelengths of 1064 nm and 532 nm, the Q5 laser effectively targets a wide range of tattoo ink colors, including black, blue, green, and red, making it one of the industry-standard solutions for multi-color tattoo removal. The 1064 nm wavelength penetrates deeper layers to remove darker pigments, while the 532 nm wavelength is ideal for treating superficial and lighter-colored pigments.

This versatile system is also highly effective in treating freckles, age spots, sun damage, birthmarks, moles, and other pigmented lesions, improving overall skin clarity and tone. Its adjustable spot sizes (2 mm, 4 mm, and 6 mm) and customizable fluence settings provide clinicians with precise control for safe and personalized treatment.

With pulse widths as short as 3 nanoseconds, the Q5 delivers powerful and controlled energy bursts that fragment pigment particles efficiently, allowing the body to naturally eliminate them over time. Multiple pulse repetition rates offer flexibility for various treatment types and skin conditions.

Designed for dermatology clinics, medical spas, and aesthetic practices, the Q5 Cosmetic General system combines performance, precision, and reliability in a compact and user-friendly platform.

Key Features

• Advanced Q-Switched Nd:YAG laser technology

• Dual wavelengths: 1064 nm and 532 nm

• Effective for multi-color tattoo removal

• Treats pigmented lesions, freckles, age spots, and birthmarks

• Nanosecond pulse duration for precise pigment targeting

• Adjustable spot sizes for treatment versatility

• High energy output up to 12.5 J/cm²

• Multiple pulse frequency settings

• Professional-grade aesthetic laser system

Applications

• Tattoo removal (multi-color including black, blue, red, and green)

• Freckles removal

• Age spot treatment

• Birthmark treatment

• Pigmented lesion treatment

• Mole removal

• Sun damage treatment

• Skin pigmentation correction

Technical Specifications

• Laser Type: Q-Switched Nd:YAG Laser

• Wavelength:

  • 1064 nm

  • 532 nm

  • Mixed mode 1064/532 nm

• Spot Sizes: 2 mm, 4 mm, 6 mm

• Fluence: Up to 12.5 J/cm²

• Pulse Width: 3 ± 1 ns

• Pulse Rate: Single Shot, 1 Hz, 2 Hz, 5 Hz, 10 Hz

• Electrical Requirements: 100–240 V, 50/60 Hz
