Standard Module:
NIBP, SPO2, ECG, CO2 and Gases
The Mindray DPM7 is a muti-parameter patient monitor that comes with a unique split-screen feature. This allows operators to view 5-Lean ECG while analyzing the real-time data. Making the DPM7 an asset to have in your ICU or Operating Room. The Mindray patient monitor comes with a 17 inch touchscreen display and resolution making it easier to monitor patients. The Mindray patient monitor has a broad range of monitoring capabilities including: providing clinicians with multi-vector arrhythmia monitoring, as well as 3, 5, and 12-lead ECG monitoring, RESP, NIBP, ST analysis, CO, CCO/SVO2, CO2, 8 invasive blood pressures, and 5-agent multi-gas analysis with auto-ID and data storage.
The DPM 7 offers a broad range of patient monitoring features well-suited for the mid to high acuity patient care environments. Incorporating the features that make monitoring easier – a 12.1" touchscreen display with optimal display visibility, quick-access menus, easy touch function keys, and multiple trend capabilities – the DPM 7 was made with the clinical user in mind. For use in the critical care environment, the DPM 7 offers a wide range of parameters and features well suited for these acuity levels such as multi-lead arrhythmia and ST analysis, cardiac output (CO), continuous cardiac output (CCO/SVO2) and up to 8 invasive blood pressures. For the OR, the DPM 7 offers an optional multi-gas module, BIS technology, and MAC measurements for a complete anesthesia monitor package. Delivering enhanced capability, modular scalability, at an extraordinary value – the DPM 7 fits your diverse monitoring needs.
Key Features
- 12.1" high resolution touchscreen display
- Robust measurement set for mid to high acuity environments
- Enhanced data storage and recall capabilities
- 3, 5, and 12-lead ECG
- Arrhythmia and ST analysis
- Up to 8 invasive blood pressures
- CCO/SVO2 capability when interfacing with Vigilance II®
- Cardiac output, pulmonary artery wedge pressure, and hemodynamic calculations provide the tools for cardiac monitoring
- SpO2: Masimo SET® (standard) or Nellcor® OxiMax®
- CO2: DPM Sidestream or Oridion® Microstream®
- Optional BIS™ technology
- Available multi-gas module
- Defibrillator synchronization
- Wireless 2.4Ghz (802.11g)
Extended data storage and recall capabilities
- 120 hours of graph and list trends
- 48 hours of full disclosure waveform review
- NIBP recall for 1,000 most recent measurements
- Alarm event review for up to 100 physiological alarm episodes
- Alarm event review for up to 100 arrhythmia alarm episodes
